ACS Traditional Floor Screed is a mixture of double washed, graded coarse sands and cement. The sand used is rigorously screened and sieved to create a free flowing under tile screed that resists shrinking during drying.
The majority of clay fines from the sand have been removed during washing to reduce water demand and subsequent shrinkage in the screed bed.
Suitable for internal and external floor applications, including balconies, bathroom floors and shower bases.
Do not use:
- On wooden, rubber, or metal substrates unless the minimum bed thickness is 40mm and is reinforced with an appropriate wire mesh.
- Where a bed thickness of less than 5mm is required
All substrates must be dry, solid, structurally sound, free of loose particles, paint, grease, oil, wax, dust and any contamination.
Cementitious substrates, such as concrete, must not be subject to shrinkage after the installation of ACS Traditional Floor Screed.
Fibre cement sheet substrates must be fixed in accordance to the manufacturers instructions and the relevant Australian Standards.
If placing ACS Screed directly onto concrete floors, prime with ACS NeoLastic diluted 2:1. Highly absorbent substrates should be primed with ACS NeoLastic diluted 1:1.
Machine Mixing: Place the screed into a mixer, then add 2 litres of clean water per 20kg bag of ACS Traditional Floor Screed. Mix thoroughly for 3-5 minutes
Drill Mixing: Place 2 litres of clean water into a clean container and slowly add 20kg of ACS Traditional Floor Screed while slowly mixing with a low speed mixer. Mix thoroughly to a smooth, homogeneous consistency
Hand Mixing: Place the screed into a wheelbarrow or onto a clean solid surface, then add 2 litres of clean water per 20kg bag of ACS Traditional Floor Screed. Mix with a shovel until a uniform consistency is achieved.
Applying the Screed
Place the mixed product onto the area to be screeded and screed to the desired thickness and plane using an appropriate straight-edge.
Apply the desired surface finish using a wooded or polyurethane float.
Bonded Screeds: Apply a primer coat of ACS Neolastic mixed 1:1 with water on to the substrate. Place the mixed ACS Screed onto the bond coat while it is still wet. Apply the finish as described previously.
Note: ACS Screed should be carefully applied at a minimum thickness of 25mm per application.
Un-bonded Screeds: Apply the mixed ACS Screed onto a polyethylene film, building paper, waterproofing membrane etc. and finish as described previously. The minimum bed thickness should be 40mm
For external applications, areas subject to vehicular traffic or point loads, mix ACS Screed with ACS Neolastic diluted 1:1 with water.
Discard any material that has exceeded the pot life or working time of the product.
Tiles may be installed immediately using the Wet-bed Method or with an appropriate tile adhesive when ACS Screed has fully cured, usually after 7 days.
It is essential that movement joints are carried through the tile, the adhesive and the screed and are kept free from dust, adhesive and other contaminants.
Refer to AS 3958.1 – 2007 for guidance on design and construction of movement joints.
Floors are ready to receive light foot traffic after approximately 24 hours and may be put into full use after approximately 7 days.
20kg of ACS Screed will cover approximately 1m2 at a thickness of 10mm.
Stored in original, unopened packaging, in cool, dry conditions, ACS Traditional Floor Screed will keep for 6-12 months. Storing in areas of high humidity or excess moisture may affect the contents and shorten shelf-life.
Health and Safety
During use, avoid inhalation of dust and contact with the skin and eyes. Wear suitable clothing, gloves, eye protection and respiratory protective equipment.
If contact with the skin occurs, thoroughly clean the area with plenty of fresh water and soap.In case of contact with the eyes rinse with plenty of fresh water and seek medical advice.
If swallowed, seek medical attention immediately – do not induce vomiting. For further information consult the Safety Data Sheet (SDS) and read the product label carefully before use.
